High discharge pressure submersible screw pump QGD
- FOB Price
US $900.01 - 40000 set
US $50.040001 - 999999 set
- group name
- CENTRIFUGAL WATER PUMP
- Min Order
- 1 set
- brand name
- RONDA
- model
- QGD
- Nearest port for product export
- Ningbo, Shanghai
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, DAF, DES
- Acceptable payment methods
- T/T, L/C, D/P D/A, Credit Card, PayPal, Westem Union, Cash, Escrow
- update time
- Fri, 22 Nov 2024 20:56:03 GMT
Paramtents
Theory Axial Flow Pump
Structure Screw Pump
Usage Water
Power Electric
Standard or Nonstandard Standard
Pressure High Pressure
Application Submersible
Packging & Delivery
-
Min Order1 set
Briefing
Submersible screw pump QGD used for water, syrup, chemical with high discharge pressure and head. Single phase.
Detailed
High discharge pressure submersible screw pump QGD
Submersible screw pump QGD used for water, syrup, chemical with high discharge pressure and head. Single phase.
1Phas or 3Phase
Material: SS304/SS316.
Structure o pump: SS Rotor / Rubber Stator.
Application of pump: Irrigation, deep well, water boosting, water supply, mines, foodstuff, resin, chemical.
| Model | Rated flow (m3/h) | Rated head (m) | Rated power (kw) | Phase | Weight (kg) | Packing (mm) | Hose fitted (inch) | Head range (m) |
| QGD1-50-0.28 | 1 | 50 | 0.28 | 1 | 12 | 95×540 | 1 | 0-52 |
| QGD1.2-50-0.37S | 1.2 | 50 | 0.37 | 1 | 12 | 95×528 | 1 | 0-52 |
| QGD1.2-50-0.37A | 1.2 | 50 | 0.37 | 1 | 13.5 | 102×540 | 1 | 0-52 |
| QGD1.2-50-0.37C | 1.2 | 50 | 0.37 | 1 | 11 | 98×530 | 1 | 0-52 |
| QGD1.8-50-0.50A | 1.8 | 50 | 0.5 | 1 | 14 | 102×550 | 1 | 0-52 |
| QGD1.2-100-0.55A | 1.2 | 100 | 0.55 | 1 | 22 | 127×620 | 1 | 0-105 |
| QGD2.5-50-0.55A | 2.5 | 50 | 0.55 | 1 | 22 | 127×615 | 1.5 | 0-52 |
| QGD2.5-50-0.55 | 2.5 | 50 | 0.55 | 3 | 22 | 127×580 | 1.5 | 0-52 |
| QGD1.8-100-0.75A | 1.8 | 100 | 0.75 | 3 | 24 | 127×620 | 1 | 0-105 |
| QGD1.8-100-0.75 | 1.8 | 100 | 0.75 | 3 | 22 | 127×620 | 1 | 0-105 |
| QGD2-1.5-0.8A | 2 | 105 | 0.8 | 3 | 25 | 127×680 | 1 | 0-110 |
| QGD5-50-1.1 | 5 | 50 | 1.1 | 3 | 27 | 160×615 | 2 | 0-52 |
| QGD5-100-2.2 | 5 | 100 | 1.2 | 3 | 42 | 160×910 | 2 | 0-105 |
