QDL/QDLF vertical centrifugal hot water circulation pump
- FOB Price
US $3000.01 - 40000 set
US $100.040001 - 999999 set
- group name
- CENTRIFUGAL WATER PUMP
- Min Order
- 1 set
- brand name
- RONDA
- model
- QDL/QDLF
- Nearest port for product export
- Ningbo, Shanghai
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, DAF, DES
- Acceptable payment methods
- T/T, L/C, D/P D/A, Credit Card, PayPal, Westem Union, Cash, Escrow
- update time
- Sat, 23 Nov 2024 03:03:48 GMT
Paramtents
Theory Centrifugal Pump
Structure Multistage Pump
Usage Water
Power Electric
Standard or Nonstandard Standard
Fuel Electric
Pressure High Pressure
Application Water
Packging & Delivery
-
Min Order1 set
Briefing
2.High quality material
3.Transfer clean medium
4.Little noise,small volume
Detailed
QDL/QDLF vertical centrifugal hot water circulation pump
1. Introduction:
1. QDL/QDLF vertical centrifugal hot water circulation pump is working smoothly and stable.
2. Inner impeller, case and other major parts are made of high quality stainless steel and bearing bush, shaft sleeve are made of hard steel alloy.
3. It's an advanced pump in stable running with little noise, long service time, small volume and light.
4. Can be used as a boiler feeding pump. Widely used in pressure boosting of living water and high building water supply.
5. Used to transfer clean hot and cold medium without solid and fiber, no-flammable and non-explosive.
6. The stainless steel one could also pump the brackish water, mineral water, distilled water, water of swimming pool or other liquid which is muriatic.
2. Product details:
| Working Principle: | Centrifugal, Multi-stage |
| Main applications: | Water |
| Driver: | Electric motor |
| Power Specs: | 380/415V 3phase; 220/240V 1phase; 50hz/60hz,etc |
| Max.permissible fluid temperature: | 120°C(248°F) |
| Type of connection: | Flange |
| Installation position: | Horizontal |
| Casing/Inner parts material: | Cast iron, Stainless steel /Cast iron, Stainless steel |
| Shaft seal type: | Mechanical seal |
| Free passage: | 0.1 mm |
| Maximum drive rating: | 45KW(60HP) |
| Maximum caliber: | 125mm(5inch) |
| Maximum dischrage-side pressure: | 2.55MPa(25.5bar) |
| Maximum head: | 255m(836.4ft) |
| Flow rate range: | 1-110m3/h(4.4-484US.GPM) |
3. Performance data:
| QDL2/QDLF2 | ||||||||||
| Model | Power | Capacity | 1 | 1.2 | 1.6 | 2 | 2.4 | 2.8 | 3.2 | 3.5 |
| (KW) | (m3/h) | |||||||||
| QDL2-20 | 0.37 | Head | 18 | 17 | 16 | 15 | 13 | 12 | 10 | 8 |
| QDL2-30 | 0.37 | (m) | 27 | 26 | 24 | 22 | 20 | 18 | 15 | 12 |
| QDL2-40 | 0.55 | 36 | 35 | 33 | 30 | 26 | 24 | 20 | 16 | |
| QDL2-50 | 0.55 | 45 | 43 | 40 | 37 | 33 | 30 | 24 | 20 | |
| QDL2-60 | 0.75 | 53 | 52 | 50 | 45 | 40 | 36 | 30 | 24 | |
| QDL2-70 | 0.75 | 63 | 61 | 57 | 52 | 47 | 41 | 35 | 28 | |
| QDL2-90 | 1.1 | 80 | 78 | 73 | 67 | 61 | 54 | 45 | 37 | |
| QDL2-110 | 1.1 | 98 | 95 | 89 | 82 | 73 | 64 | 54 | 44 | |
| QDL2-130 | 1.5 | 116 | 114 | 106 | 98 | 89 | 78 | 65 | 52 | |
| QDL2-150 | 1.5 | 134 | 130 | 123 | 112 | 10 | 90 | 73 | 60 | |
| QDL2-180 | 2.2 | 161 | 157 | 148 | 136 | 121 | 108 | 91 | 76 | |
| QDL2-220 | 2.2 | 197 | 192 | 180 | 165 | 148 | 130 | 110 | 90 | |
| QDL2-260 | 3 | 232 | 228 | 214 | 198 | 179 | 158 | 130 | 110 | |
| QDL4/QDLF4 | ||||||||||
| Model | Power | Capacity | 1.5 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
| (KW) | (m3/h) | |||||||||
| QDL4-20 | 0.37 | Head | 19 | 18 | 17 | 15 | 13 | 10 | 8 | 6 |
| QDL4-30 | 0.55 | (m) | 28 | 27 | 26 | 24 | 20 | 18 | 13 | 10 |
| QDL4-40 | 0.75 | 38 | 36 | 34 | 32 | 27 | 24 | 19 | 13 | |
| QDL4-50 | 1.1 | 47 | 45 | 43 | 40 | 34 | 31 | 23 | 17 | |
| QDL4-60 | 1.1 | 56 | 54 | 52 | 48 | 41 | 37 | 28 | 20 | |
| QDL4-80/7 | 1.5 | 66 | 63 | 61 | 56 | 48 | 43 | 33 | 24 | |
| QDL4-80 | 1.5 | 74 | 72 | 70 | 64 | 55 | 50 | 38 | 27 | |
| QDL4-100 | 2.2 | 96 | 90 | 87 | 81 | 71 | 62 | 48 | 34 | |
| QDL4-120 | 2.2 | 114 | 108 | 104 | 95 | 85 | 75 | 58 | 41 | |
| QDL4-160/14 | 3 | 136 | 126 | 122 | 112 | 101 | 89 | 68 | 48 | |
| QDL4-160 | 3 | 152 | 144 | 140 | 129 | 115 | 101 | 78 | 55 | |
| QDL4-190 | 4 | 183 | 171 | 168 | 153 | 137 | 122 | 93 | 67 | |
| QDL4-220 | 4 | 211 | 200 | 192 | 178 | 160 | 138 | 108 | 79 | |
| QDL8/QDLF8 | ||||||||||
| Model | Power | Capacity | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 |
| (KW) | (m3/h) | |||||||||
| QDL8-20 | 0.75 | Head | 21 | 20 | 19 | 18 | 17 | 16 | 15 | 14 |
| QDL8-30 | 1.1 | (m) | 31 | 30 | 29 | 28 | 26 | 24 | 23 | 20 |
| QDL8-40 | 1.5 | 41 | 40 | 39 | 37 | 35 | 32 | 30 | 27 | |
| QDL8-50 | 2.2 | 52 | 50 | 48 | 46 | 44 | 41 | 37 | 34 | |
| QDL8-60 | 2.2 | 62 | 60 | 58 | 55 | 53 | 49 | 45 | 41 | |
| QDL8-80 | 3 | 83 | 80 | 78 | 74 | 70 | 65 | 60 | 54 | |
| QDL8-100 | 4 | 104 | 100 | 97 | 92 | 88 | 80 | 75 | 68 | |
| QDL8-120 | 4 | 125 | 120 | 116 | 110 | 105 | 97 | 90 | 81 | |
| QDL8-140 | 5.5 | 146 | 140 | 136 | 129 | 123 | 113 | 105 | 95 | |
| QDL8-160 | 5.5 | 166 | 160 | 155 | 147 | 140 | 130 | 120 | 108 | |
| QDL8-180 | 7.5 | 187 | 180 | 175 | 166 | 158 | 146 | 135 | 122 | |
| QDL8-200 | 7.5 | 208 | 200 | 194 | 185 | 175 | 162 | 150 | 135 | |
| Voltages available: 220V/ 380V/ 415V/ 440V ect. | ||||||||||
Parameter table above is only a part of whole. For more, please contact us directly.
4. FAQ:
5. Pictures:
Excellent product made of carefully selected high-quality materials:
Meticulous details & fine appearance:
Safe packing with standard plywood case:
A lot of products in stock:
Goods are packed and ready to delivered:
